Nanlite MixPanel 60 Bicolor + RGB Hard and Soft Light LED Panel (15-2010)

Nanlite MixPanel 60 RGBWW LED Panel – Versatile 3-in-1 Light Source

The Nanlite MixPanel 60 is a powerhouse of versatility, uniquely combining three distinct LED light sources into one compact, portable housing. Whether you need the "throw" of a traditional hard light, the flattering wash of a soft SMD panel, or the creative freedom of Tunable RGB colors, the MixPanel 60 delivers it all at the touch of a button.

With a CRI of 98 and TLCI of 95, this panel ensures professional-grade color accuracy, saving you hours in post-production. From studio portraits to high-energy location shoots, the MixPanel 60 is the ultimate "do-it-all" lighting solution for filmmakers and photographers.

Features:

• 3-in-1 Lighting Versatility: Switch instantly between hard light, soft light, and colorful RGB light without changing accessories.
• Ultra-Bright Output & Boost Mode: Emits up to 6600 Lux @ 1m (5600K) in Boost Mode.
• Color Perfection: Exceptional color fidelity with a CRI of 98 and TLCI of 95, plus Green/Magenta adjustment for perfect matching.
• Built-in Gel Emulation: Access 43 gel presets (across 3200K and 5600K) including CTO, CTB, and Calcolor selections.
• Creative Practical Effects: Features 9 special effects including Lightning, Siren, TV, Paparazzi, and Candle/Fire.
• Intuitive Interface: A user-friendly OS allows you to save custom settings as presets for consistent, repeatable results.
• Pro Power Options: Run via the included AC adapter or 14.8V V-Mount batteries (sold separately) for total mobility.

Lux / Foot Candles

Distance and CCT		Distance and Color
@ 1m 2700K	4756 lux / 442 fc	@ 1m Red	1600 lux / 149 fc
@ 2m 2700K	1290 lux / 120 fc	@ 2m Red	429 lux / 40 fc
@ 3m 2700K	596 lux / 55 fc	@ 3m Red	198 lux / 18 fc
@ 1m 3200K	5438 lux / 505 fc	@ 1m Green	3613 lux / 336 fc
@ 2m 3200K	1485 lux / 138 fc	@ 2m Green	958 lux / 89 fc
@ 3m 3200K	690 lux / 64 fc	@ 3m Green	444 lux / 41 fc
@ 1m 5600K	5844 lux / 543 fc	@ 1m Blue	690 lux / 64 fc
@ 2m 5600K	1574 lux / 146 fc	@ 2m Blue	185 lux / 17 fc
@ 3m 5600K	729 lux / 68 fc	@ 3m Blue	85 lux / 8 fc
@ 1m 7500K	5695 lux / 529 fc
@ 2m 7500K	1534 lux / 143 fc
@ 3m 7500K	707 lux / 66 fc

Dimensions

Specification	Metric (cm/kg)	Imperial (in/lb)
Height	35.0 cm	14.0 in
Length	43.0 cm	17.0 in
Width	8.2 cm	3.0 in
Weight	3.3 kg	7.3 lb
