Nanlite MixPanel 60 RGBWW LED Panel – Versatile 3-in-1 Light Source
The Nanlite MixPanel 60 is a powerhouse of versatility, uniquely combining three distinct LED light sources into one compact, portable housing. Whether you need the "throw" of a traditional hard light, the flattering wash of a soft SMD panel, or the creative freedom of Tunable RGB colors, the MixPanel 60 delivers it all at the touch of a button.
With a CRI of 98 and TLCI of 95, this panel ensures professional-grade color accuracy, saving you hours in post-production. From studio portraits to high-energy location shoots, the MixPanel 60 is the ultimate "do-it-all" lighting solution for filmmakers and photographers.
Features:
- 3-in-1 Lighting Versatility: Switch instantly between hard light, soft light, and colorful RGB light without changing accessories.
- Ultra-Bright Output & Boost Mode: Emits up to 6600 Lux @ 1m (5600K) in Boost Mode.
- Color Perfection: Exceptional color fidelity with a CRI of 98 and TLCI of 95, plus Green/Magenta adjustment for perfect matching.
- Built-in Gel Emulation: Access 43 gel presets (across 3200K and 5600K) including CTO, CTB, and Calcolor selections.
- Creative Practical Effects: Features 9 special effects including Lightning, Siren, TV, Paparazzi, and Candle/Fire.
- Intuitive Interface: A user-friendly OS allows you to save custom settings as presets for consistent, repeatable results.
- Pro Power Options: Run via the included AC adapter or 14.8V V-Mount batteries (sold separately) for total mobility.
Lux / Foot Candles
| Distance and CCT | Distance and Color | ||
|---|---|---|---|
| @ 1m 2700K | 4756 lux / 442 fc | @ 1m Red | 1600 lux / 149 fc |
| @ 2m 2700K | 1290 lux / 120 fc | @ 2m Red | 429 lux / 40 fc |
| @ 3m 2700K | 596 lux / 55 fc | @ 3m Red | 198 lux / 18 fc |
| @ 1m 3200K | 5438 lux / 505 fc | @ 1m Green | 3613 lux / 336 fc |
| @ 2m 3200K | 1485 lux / 138 fc | @ 2m Green | 958 lux / 89 fc |
| @ 3m 3200K | 690 lux / 64 fc | @ 3m Green | 444 lux / 41 fc |
| @ 1m 5600K | 5844 lux / 543 fc | @ 1m Blue | 690 lux / 64 fc |
| @ 2m 5600K | 1574 lux / 146 fc | @ 2m Blue | 185 lux / 17 fc |
| @ 3m 5600K | 729 lux / 68 fc | @ 3m Blue | 85 lux / 8 fc |
| @ 1m 7500K | 5695 lux / 529 fc | ||
| @ 2m 7500K | 1534 lux / 143 fc | ||
| @ 3m 7500K | 707 lux / 66 fc |
Dimensions
| Specification | Metric (cm/kg) | Imperial (in/lb) |
| Height | 35.0 cm | 14.0 in |
| Length | 43.0 cm | 17.0 in |
| Width | 8.2 cm | 3.0 in |
| Weight | 3.3 kg | 7.3 lb |
